● Android 4.4 (Kit Kat) Operation Systems
● TI OMAP Dual Core 1 Ghz Proccessor
● 1 GB DDR RAM, 8 GB eMMC ROM
● 3,5 Inch (320 x 240 pixel) Color Touch Screen
● Wifi and Bluetooth Technology
● 1,8 mt (6 ft) Drop Resistance
● IP65 Protection Class
| System | ||
| Micro Processor | TI OMAP4 Dual Core 1 Ghz Proccessor | |
| Memory | 1 GB Mobile DDR RAM, 8 GB eMMC Flash ROM | |
| Operation System | Android 4.4 (Kit Kat) | |
| Expansions Slots | Micro Secure Digital slot (SDHC) up to 32 GB, User-Accessible | |
| Audio | Wideband Speech (HD Audio) | |
| Display | ||
| Display Type | Reflective | |
| Features | Dayligth Readable, With Backlight, 65K Touch Screen | |
| Dimension | 3,5" (Inch) | |
| Resolutioin | 320 x 240 Pixel | |
| Keypad | ||
| Keypad Types | 29 Keys: Numeric Or Functional Numeric | |
| 52 Keys: Alpha Numeric | ||
| Communication | ||
| USB | USB 2.0 Host (480 Mbps) | |
| RS-232C | Max. 115.200 Bps (With Cradle) | |
| WLAN | TI Wi-link 8, IEEE 802.11 a/b/g/n, 2.4 Ghz or 5 Ghz CCX4 Compliant | |
| WPAN | Bluetooth V4 BLE | |
| Ethernet | With Single Dock Cradle | |
| Electrical | ||
| Battery | Standard Battery: 3,7V 5200 mAh Li-Ion Battery | |
| Physical | ||
| Dimension | Length: 225 mm, Width: 88, Thickness: 55 mm | |
| Weight | Without Pistol: 602 gr, With Pistol: 668 gr | |
| Enviromental | ||
| Operating temperature | -20°C to 50°C | |
| Storage temperature | -30°C to 70°C | |
| Drop test to Concrete | Max. 1,8 meter | |
| Sealing | IP65 | |
| Decoding Capability | ||
| 1D / Linear | Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes. | |
| 2D Codes | Aztec Code, Data Matrix, MaxiCode, PDF417, MicroPDF417, Micro QR Code, QR Code | |
| Postal Codes | Australian Post, Japanese Post, KIX Code, Royal Mail, USPS Intelligent Mail, USPS PLANET, USPS, Postnet | |
| Stacked Codes | GS1 Composite Codes UPC/EAN/JAN Composites, GS1 DataBar Composites and GS1-128 Composite | |
| Barcode Scanner | ||
| 1D Imager | Imager Sensor | 2500 Pixel Sensor |
| Sharp green LED scan line | ||
| Resolution | 2.5 mils (linear codes) | |
| Depth of Field | 40 mm ~ 740 mm | |
|
2D Imager (Standard Range) |
Imager Sensor | Megapixel Sensor |
| White LED Illumination | ||
| Resolution | 1D: 3 mils | |
| 2D: 6,6 mils | ||
| Depth of Field | 45 mm ~ 740 mm | |
|
2D Imager (Auto Range 2D) |
Resolution | 1D: 3 mils |
| 2D: 10 mils | ||
| Depth of Field | Code 39 (10 mil): 0,15 m ~ 1,5 mt | |
| Code 39 (55 mil): ~ 8 mt | ||
| Code 39 (100 mil): ~ 15 mt | ||
| Datamatrix (10 mil): 0,15 m ~ 0,9 mt | ||
| Datamatrix (55 mil): ~ 4,8 mt | ||
| Datamatrix (100 mil): ~ 8 mt | ||
| Scan Window | Gorilla® Glass 3 | |
| Safety & Regulatory | ||
| Agency Approvals | The product meets necessary safety and regulatory approvals for its intended use. The Users Manual for this product can be referred to for a complete list of certifications | |
| Enviromental Compliance | Complies to EU RoHS | |
| Laser Classification | VLD - Class 2 IEC/EN60825-1. Compliant with 21 CFR 1040.10 except for deviations pursuant to laser notice Number 50, dated June 24, 2007. | |
| LED Classification | Exempt Risk Group IEC/EN62471 | |
| Software | ||
| Applications | Datalogic’s SoftSpot technology for configurable soft triggers, Pre-licensed device and browser lockdown powered by 42Gears, Enterprise class PTT offered by Zello | |
| Configuration and maintenance | 42 Gears SureLock pre-licensed for device lockdown | |
| SOTI MobiControl (optional) | ||
| Develepment | Datalogic Android SDK, Xamarin SDK | |
| Browser | SureFox locked web browser pre-licensed | |
| Terminal Emulation | Wavelink Velocity Terminal Emulation | |
| StayLinked SmartTE Terminal Emulation | ||
| Accessories | ||
| Accessories | Single Slot Dock | |
| Multi-Ethernet Dock Charger | ||
| Multi Charge Only Charges | ||
| Multi Battery Charger | ||
| Rubber Boot | ||
| Vehicle Dock | ||
| Standart Softcase With Quick Release Belt Clip | ||
