Newland N7
(Cachalot)
Android Handheld Terminal



● Android 10.0 (Q) Operation Systems
● GMS (Google Mobile Service) Support
● Octa Core 1,8 Ghz proccessor
● 3 GB RAM, 32 GB ROM
● 4 Inch Capacitive Touch Screen
● Wifi, Bluetooth, RFID/NFC Communication
● 29, 38, 47 Keypad Options
● 1,8 mt Drop Resistance
● IP65 Protection Class

 Model  Operation System Wifi Bluetooth 4G RAM ROM
 N7-AER-7KJF-F  Android 10.0 (Q) Yes Yes None 3 GB 32 GB
 N7-W-S3  Android 10.0 (Q) Yes Yes None 4 GB 64 GB
System
 Micro Processor Qualcomm Snapdragon 1,8 Ghz 64 Bit Proccessor
 Memory 3 GB RAM, 32 GB Flash ROM
 Operation System Android 10.0 (Q) GMS and AER support
 Notification Vibrator, Muli Color LED and Speaker
 Camera 13 Megapixels, PDAF, auto focus, with LED flashlight
 Keypad 29, 38, 47 physical buttons, with backligth function
 Sensors Gravity Sensor, Hall Switch
 Display
 Display Type WVGA
 Touch Screen Type Capacitive
 Dimension 4" (Inch)
 Resolutioin 800 x 480 Pixel
 Features IPS screen with Gorilla Glass, supports input with gloves
 Barcode Scanner
 Type 2D Area Imager
 Optical System Imager
 Aiming Laser Diode
 Supported Barcode Types 1D All major 1D symbologies, including Code 128, Code 49, Code 16K, (GS1128) UCC EAN-128, AIM-128, EAN-8, EAN-13, UPC·E, UPC-A, ITF, ITF 6, ITF 14, Matrix 2 of 5, Industrial 25, Standard 2 of 5, Code39, ISSN, ISBN, Codabar, Code93, Code 11, Plessey, MSI Plessey, RSS.
2D All major 2D symbologies, including Aztec, Composite, CS Code, Maxicode, Micro PDF, Micro QR, PDF 417, QR Code, Data Matrix, DotCode.
 Depth Of Field SR Model 1D Code 39 (5 Mil): 80 mm - 350 mm
EAN-13 (13 Mil): 40 mm - 480 mm
2D PDF417 (6,6 Mil): 60 mm - 320 mm
Datamatrix (10 Mil): 55 mm - 355 mm
QrCode (15 Mil): 50 mm - 400 mm
MR Model 1D Code 39 (5 Mil): 200 mm - 575 mm
EAN-13 (13 Mil): 130 mm - 705 mm
2D PDF417 (6,6 Mil): 175 mm - 550 mm
Datamatrix (10 Mil): 185 mm - 520 mm
QrCode (15 Mil): 195 mm - 550 mm
 Communication
 USB QC3.0, Type-C (9V/2A)
 Wifi Frequency 2.4GHz and 5GHz
Protocol 802.11 a/b/g/n/ac (802.11 d/h/i/k/r/v/w compatible)
Roaming Super Fast Roaming
 Bluetooth Dual Mode, Bluetooth 4.2+LE (Backward compatible)
 WWAN TD-LTE (B38, B39, B40, B41) FDD-LTE (B1, B2, B3, B5, B7, B8, B20, B28 a&b)
SIM Slot: Mini SIM
 GPS Beidou, Galileo, GLONASS, GPS (AGPS)
 RFID Frequency: 13,36 Mhz
Supported Tags: IS014443A/B, Ml FARE, Felica, NFC Forum Tags
 Electrical
 Power Supply (Input) AC100 ~ 240V, 50 ~ 60Hz
 Power Supply (Output) 5V/2A, 9V/2A, 15V/1.2A
 Main Battery 3.8V, 5100 mAh (Removable)
 Battery Life Operation : Max. 15 Hours
Standby : ~ 500 Hours
 Physical
Dimensions Width 70 mm
Height 200 mm
Thickness 29 mm (58 mm With pistol grip)
Weight 360g (including battery)
 Enviromental
 Operating temperature -20°C to 55°C
 Storage temperature -40°C to 70°C
 Humidty %5 ~ %95 (Non Condensing)
 ESD ±15 kV (Air Discharge), ±8 kV (Direct Discharge)
 Drop 1,8 meter
 Sealing IP65
 Certifications
 Hardware CE-RED, FCC, BIS, RoHS2.0, REACH, AER, SOTI, UN38.3, IEC62471
 Laser Safety IEC60825
 Accessories
 Accessories
(Optional Items)
USB Cable
Single Charging Cradle
Battery
Multi Plug Adapter (supports fast charging)
Hand Strap
Pistol Grip
4 Slot Charger
