● Direct Thermal And Thermal Printing
● 203 DPI Printing Resolution
● Max. 104 mm Printing Width
● Max. 2286 mm Printing Length
● Max. 127 mm / Sec Printing Speed
● 8 MB DRAM and 8 MB Flash ROM
● TSC and ZPL Emulation Support
● USB, RS232C, LPT and Ethernet Port
Operational | ||
Printing method | Direct thermal and thermal transfer | |
Printing resolution | 203 DPI (8 dots/mm) | |
Printing speed (Maximum) | 102 ~ 127 mm/saniye | |
Printing length | 10 mm ~ 2.286 mm | |
Printing width | Max. 104 mm | |
Sensor | 1 Pcs Reflective Label Sensor (Movable and at the bottom) | |
1 Pcs Reflective Label Sensor (Movable and at the Top) | ||
1 Pcs Print Head Open Sensor | ||
Print directions | 0, 90, 180, 270 degree | |
Memory | 8 MB DRAM, 8 MB Flash ROM | |
Operation interface | 1 Button and 2 LED | |
Communication interface | RS-232C, USB, LPT and Ethernet | |
Physical | ||
Width | 223 mm | |
Height | 286 mm | |
Depth | 169 mm | |
Weight | 2,35 kg | |
Material | ABS Plastic | |
Label | ||
Type | Continuous, Gap, Fan hold, Black Mark | |
Width | 20 mm ~ 120 mm | |
Thickness | 0,058 ~ 0,305 mm | |
Media Gap | Min: 2 mm | |
Roll Inside Diameter | 25,4 mm ~ 38 mm | |
Roll Outside diameter | 127 mm (Maximum) | |
Ribbon | ||
Type | Wax, Wax/Resin and Resin | |
Ink side | Outside | |
Width | 30 mm ~ 110 mm | |
Length | 300 Meter (Maximum) | |
Roll Inside Diameter | 25,4 mm | |
Roll Outside Diameter | 67 mm (Maximum) | |
Electrical | ||
Power Type | External Power Adaptor (Built-in automatic voltage switching power supply) | |
Power source (Input) | AC100 – 240V | |
Power source (Output) | DC24V / 2.5A (50/60W) | |
Environmental | ||
Operation temperature | 5°C ~ 45°C | |
Storage temperature | -10°C ~ 50°C | |
Operation Humidty | %25 ~ %85 (Non Condensing) | |
Storage Humidty | %10 ~ %90 (Non Condensing) | |
Software | ||
Windows drivers | Windows 2000/Xp/Vista/7/8/10, Windows Server 2003/2008 | |
Linux drivers | Supported | |
Label Design Software | Nicelabel SE | |
Supported Command Set | TSC and ZPL | |
Supported graphics formats | BMP and PCX | |
Character Fonts | Character Set | Nicelabel SE |
Print Fonts | ASCII Font A: 12*24 | |
ASCII Font B: 9*24 | ||
Chinese: 42*24 | ||
Supported Barcode Types | ||
1D | Code 39, Code 93, PCX ITF, EAN 128, Code 128, subsets A,B,C, Codabar, EAN-8, EAN-13, UPC-A, UPC-E, EAN ve UPC 2(5, digit add-on, MSI, MSIC, Plessey, Cpost, ITF14, EAN14 | |
2D | QRCode | |
Accessories | ||
Optional Items | External Media Holder |
