● Direct Thermal Printing
● 203 DPI Printing Resolution
● Max. 54 mm Printing Width
● Max. 2540 mm Printing Length
● Max. 177 mm / Sec Printing Speed
● 32 MB DRAM and 16 MB Flash ROM
● PPLA, PPLB and PPLZ Support
● USB, USB Host and Ethernet Port
Print Specifications | |
Printing method | Direct Thermal |
Printing resolution | 203 DPI (8 dots/mm) |
Printing speed (Maximum) | 177,8 mm/sec |
Printing length | Mmax. 2540 mm |
Printing width | Max. 54 mm |
Memory | 32 MB DRAM and 16 MB Flash ROM (USB storage up to 32GB) |
Proccessor | 32 Bit RISC proccessor |
Consumables Specifications | |
Sensors | Reflective sensor x 1 (movable) |
Transmissive sensor x 1 (fixed, 6.27mm offset) | |
Media Type | Roll-feed, die-cut, continuous, fan-fold, black mark, tags, ticket in thermal paper or plain paper |
Media | Max. width 60mm. Min. width 12mm. Media thickness: 0.06~0.2mm 5”(127mm) OD on a 1”/1.5” (25.4/38 mm) ID core; 4.5”(114mm) OD on a 0.5” (12.7mm) ID core |
Fonts & Symbologies | |
Fonts | Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24x24 4 direction 0 ~ 270 rotation Soft fonts are downloadable Ability to print any Windows True Type font easily. Support scalable font |
1D Barcodes | UPC-A, UPC-E, JAN/EAN, CODE39, CODE93, CODE128, GS1-128 (UCC/EAN128), CODABAR (NW-7), ITF, Industrial 2of5, MSI, UPCadd-on code, POSTNET, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirecional, GS1DataBar Limited, GS1 DataBar Expanded, GS1DataBar Expanded Stacked |
Len2D Barcodes | QR Code, PDF417 (includingMicroPDF), DataMatrix (ECC200), GS1 DataMatrix, MaxiCode |
Graphics | PPLA: PCX, BMP, IMG, HEX,GDI PPLB: PCX, BMP, Binary raster, GDI PPLZ: GRF, Hex, GDI |
Emulation | PPLA, PPLB, PPLZ |
Electrical | |
Power input type | External adaptor |
Power source (Input) | 100V~240V±10%, 1.8A, 50~60Hz |
Power source (Output) | 24VDC, 2.4A, 60 W Max. |
Interface Characteristics and Integration | |
Operation Interface | LED Indicator x 2, Botton(Feed) x 1 |
Communication Interface | USB device, USB host |
Software-label Editing | Windows Driver for Vista/Win7/Win8/Win10, BarTender® from Seaguall Scientific |
Software-Utility | Printer Tool |
Database Link | Argobar Pro support ODBC Database Connection: Excel, CSV, MS Access, MS SQL, Oracle MySQL, dBASE (*.dbf) |
Operating & Environment Characteristics | |
Power Source | Universal Switching Power supply. AC input voltage: 100~240V, 50~60Hz. DC Output: 24V, 2.5A |
Operation Environment | Operation Temperature: 41°F~104°F (5°C~40°C), 0% ~ 90% non-condensing, Storage Temperature: -4°F~122°F (-20°C~50°C) |
Agency Listing | CE, FCC, TUV/cTUVus, Energy Star, CCC, RoHS, BSMI |
Physical Characteristics | |
Printer Dimensions | W 116mm x H 170mm x D 215mm |
Printer Weight | 2.31 lbs (1.05 kg) |
