● Direct Thermal Printing
● 203 DPI Printing Resolution
● Max. 72 mm Printing Width
● Max. 2540 mm Printing Length
● Max. 102 mm / Sec Printing Speed
● 8 MB DRAM, 4 MB Flash ROM
● PPLA and PPLB Support
● Internal Real Time Clock
● Tear off bar Built-in
● RS-232C, USB port and Cash Drawer Port
Operational | |
Printing method | Direct thermal (Printing Without Ribbon) |
Printing resolution | 203 DPI (8 dots/mm) |
Printing speed (Maximum) | 102 mm/sec |
Printing length | 13 ~ 2540 mm |
Printing width | 25 mm ~ 72 mm |
Memory | 8 MB DRAM and 4 MB Flash ROM |
Proccessor | 32 Bit RISC proccessor |
Operation interface | 1 button (Feed) and 2 LED (Power and Ready) |
Communication interface | RS-232, USB, Cash drawer |
Sensor | Reflective (Fixed and Left Side) |
Real Time Clock | Standart |
Print directions | 0, 90, 180, 270 degree |
Agency listing | CE, FCC, cTUVus, CCC, RoHS |
Physical | |
Width | 134 mm |
Height | 163 mm |
Length (Depth) | 228 mm |
Weight | 1,2 kg |
Material | ABS Plastic |
Electrical | |
Power input type | External adaptor |
Power source (Input) | 100V~240V±10%, 1.8A, 50~60Hz |
Power source (Output) | 24VDC, 2.5A |
Environmental | |
Operation temperature | 4 °C ~ 38 °C |
Storage temperature | -20 °C ~ 50 °C |
Humidty | %10 ~ %90 (Non Condensing) |
Label | |
Type | Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper |
Width | 25,4 mm ~ 77 mm |
Thickness | 0.0635 ~ 0.254 mm |
Length | 2540 mm (Max.) |
Ribbon | |
Type | Not Used |
Software | |
Windows drivers | Windows 2000/XP/2003/VISTA/Windows 7 |
Label Design programs | Bartender UltraLite (Free) |
Utility programs | Printer Utility and Font Utility |
Supported barcode printing language | PPLA, PPLB |
Supported graphics formats |
PPLA:
CX, BMP, IMG, HEX and GDI PPLB: PCX, BMP, IMG, HEX, GDI and Binary Raster |
Supported Barcode Types | |
1D |
PPLA: Code 39
(standard/with checksum digit),
Code 93 Interleaved 2of 5
(standard /with checksum
digit/with human readable check
digit), EAN-8,
EAN-13,UPC-A,UPC-E,Postnet,
Codabar, Code 128 subset A/B/C,
UCC/EAN-128, UCC/EAN-128 K-MART,
UCC/EAN-128 , Random Weight,
Plessey, HBIC, Telepen, FIM,
UPC2, UPC5,GS1 DataBar |
2D | PPLA/PPLB: MaxiCode, PDF417, Data Matrix (ECC200 Only), QR code, Composite codes |
Accessories | |
Optional Items | Rotary Cutter |
Guillotine Cutter | |
Dispencer | |
Stacker |
