Operational |
|
Printing method |
Direct Thermal and Thermal Transfer |
|
Printing resolution |
203 DPI (8 dots/mm) |
|
Printing speed (Maximum) |
203 mm/saniye |
|
Printing length |
Max. 2540 mm |
|
Printing width |
Max. 108 mm |
|
Memory |
32 MB DRAM, 16 MB Flash ROM |
|
Proccessor |
32 bit RISC micro proccessor |
|
Operation interface |
3 Button (Feed, Pause and
Cancel) |
|
3 LED (Ready, Media and Ribon) |
|
With Backligth Color Display (16x2 Line) |
|
Communication
interface |
Ethernet, Çift USB Host, USB ve RS-232C |
|
Real Time Clock |
Standart |
|
Sensor |
Reflective and transmissive
media sensor
(Movable) |
|
Head open switch sensor |
|
Ribbon end sensor |
|
Print directions |
0, 90, 180, 270 degree |
|
Agency listing |
CB, CE, FCC, cTUVus, ICES, Energy Star |
|
Physical |
|
Width |
250 mm |
|
Height |
263 mm |
|
Length (Depth) |
418 mm |
|
Weight |
11 kg |
|
Material |
Metal |
|
Electrical |
|
Power input type |
Power Cable |
|
Power source (Input) |
100 ~ 240V, 5A, 50/60 Hz |
|
Environmental |
|
Temperature |
Operation:
4 °C ~ 40 °C |
|
Storage :
-20 °C ~ 50 °C |
|
Humidty |
Operation: %30 ~ %85 (Non Condensing) |
|
Storage: %10 ~ %90 (Non Condensing) |
|
Label |
|
Type |
Roll-feed, die-cut, continuous,
fan-fold, tags, ticket in
thermal paper or plain paper |
|
Width |
25,4 mm ~ 114 mm |
|
Thickness |
0.0635 ~ 0.254 mm |
|
Roll Inside diameter |
38 mm ~ 76 mm |
|
Roll Outside diameter |
Max. 177,8 mm (With 38 mm ID Core) |
|
Max. 210 mm (With 76 mm ID Core) |
|
Ribbon |
|
Type |
Wax, Wax/Resin and Resin |
|
Ink side |
Inside / Outside |
|
Width |
25,4 mm ~ 112 mm |
|
Length |
450 Meter (Max.) |
|
Roll Inside diameter |
25,4 mm |
|
Roll Outside diameter |
81,3 mm (Max.) |
|
Software |
|
Windows
drivers |
Win XP / Vista / 7 / 8 / 8.1 / Win 10, Windows Server 2003 / 2008 / 2012 (32 Bit & 64 Bit) |
|
Label
Design programs |
Bartender UltraLite
(Free) |
|
Utility
programs |
Printer Utility and Font Utility |
|
Supported barcode printing
language |
PPLA, PPLB and PPLZ |
|
Supported graphics formats |
PPLA: PPCX, BMP, IMG, HEX ve GDI formats |
|
PPLB: PCX, BMP, Binary raster and GDI formats |
|
PPLZ:GRF, Hex ve GDI Formats |
|
Supported Barcode Types |
|
1D |
UPC-A, UPC-E, JAN/EAN, CODE39, CODE93, CODE128, GS1-128 (UCC/EAN128), CODABAR (NW-7), ITF, Industrial 2of5, MSI, UPCadd-on code, POSTNET, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1DataBar Limited, GS1 DataBar Expanded, GS1DataBar Expanded Stacked
|
|
2D |
QR Code, PDF417 (including MicroPDF), DataMatrix (ECC200), GS1 DataMatrix, MaxiCode |
