● Direct Thermal And Thermal Printing
● 203 DPI Printing Resolution
● Max. 108 mm Printing Width
● Max. 2540 mm Printing Length
● Max. 152 mm / Sec Printing Speed
● 32 MB DRAM and 16 MB Flash ROM
● PPLA, PPLB and PPLZ Barcode Print Language Support
● Ethernet, RS-232C, USB Client and Dual USB Host Port
● Windows and Linux Driver Support
Operational | |
Printing method | Direct Thermal and Thermal Transfer |
Printing resolution | 203 DPI (8 dots/mm) |
Printing speed (Maximum) | 152 mm/saniye |
Printing length | Max. 2540 mm |
Printing width | Max. 108 mm |
Memory | 32 MB DRAM, 16 MB Flash ROM |
Proccessor | 32 bit RISC micro proccessor |
Operation interface | 3 Button (Feed, Pause and Cancel) |
3 LED (Ready, Media and Ribon) | |
Communication interface | Ethernet, Çift USB Host, USB ve RS-232C |
Sensor | Reflective and transmissive media sensor (Movable) |
Head open switch sensor | |
Ribbon end sensor | |
Print directions | 0, 90, 180, 270 degree |
Agency listing | CE, CB, cULus, FCC, ICES, Energy Star, RoHS, BSMI |
Physical | |
Width | 250 mm |
Height | 263 mm |
Length (Depth) | 418 mm |
Weight | 11 kg |
Material | Metal |
Electrical | |
Power input type | Power Cable |
Power source (Input) | 100 ~ 240V, 5A, 50/60 Hz |
Environmental | |
Temperature | Operation: 4 °C ~ 40 °C |
Storage : -20 °C ~ 50 °C | |
Humidty | Operation: %30 ~ %85 (Non Condensing) |
Storage: %10 ~ %90 (Non Condensing) | |
Label | |
Type | Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper |
Width | 25,4 mm ~ 114 mm |
Thickness | 0.0635 ~ 0.254 mm |
Roll Inside diameter | 38 mm ~ 76 mm |
Roll Outside diameter | Max. 177,8 mm (With 38 mm ID Core) |
Max. 210 mm (With 76 mm ID Core) | |
Ribbon | |
Type | Wax, Wax/Resin and Resin |
Ink side | Inside / Outside |
Width | 25,4 mm ~ 112 mm |
Length | 450 Meter (Max.) |
Roll Inside diameter | 25,4 mm |
Roll Outside diameter | 81,3 mm (Max.) |
Software | |
Windows drivers | Win XP / Vista / 7 / 8 / 8.1 / Win 10, Windows Server 2003 / 2008 / 2012 (32 Bit & 64 Bit) |
Label Design programs | Bartender UltraLite (Free) |
Utility programs | Printer Utility and Font Utility |
Supported barcode printing language | PPLA, PPLB and PPLZ |
Supported graphics formats | PPLA: PPCX, BMP, IMG, HEX ve GDI formats |
PPLB: PCX, BMP, Binary raster and GDI formats | |
PPLZ:GRF, Hex ve GDI Formats | |
Supported Barcode Types | |
1D | UPC-A, UPC-E, JAN/EAN, CODE39, CODE93, CODE128, GS1-128 (UCC/EAN128), CODABAR (NW-7), ITF, Industrial 2of5, MSI, UPCadd-on code, POSTNET, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1DataBar Limited, GS1 DataBar Expanded, GS1DataBar Expanded Stacked |
2D | QR Code, PDF417 (including MicroPDF), DataMatrix (ECC200), GS1 DataMatrix, MaxiCode |
