Operational |
|
Light source |
625 nm visible LED |
|
Optical system |
2.500 pixel linear sensor |
|
Depth of field |
0 – 50 mm (0,33 mm, PCS=90%) |
|
Microproccessor |
32 Bit |
|
Scan Rate |
150 scans/sec |
|
Minimum Bar Width |
0,0762 mm (3 mil) (Code 39) >
60% PCS) |
|
Print Contrast |
25% @ UPC/EAN 100% |
|
Indicators (LED) |
Two Color LED |
|
Beeper Operation |
Programmable tone & beep time |
|
System Interfaces |
Keyboard, RS-232C, HID USB, USB
virtual COM port, wand, Opos and
Jpos |
|
Physical |
|
Heigth |
165,7 mm |
|
Width |
72,5 mm |
|
Heigth |
54 mm |
|
Weight |
100 g (cable excluded) |
|
Cable |
Standard 2 meter straight |
|
Material |
ABS Plastic |
|
Electrical |
|
Input Voltage |
5 VDC ±5% |
|
Operating Current |
90 mA
(AVG), 150 mA (max.) |
|
Standby Current |
55 mA typical |
|
EMC |
CE & FCC DOC compliance, VCCI,
BSMI |
|
Environmental |
|
Operation temperature |
0°C ~ 50°C |
|
Storage temperature |
-20 °C ~ 60 °C |
|
Humidty |
%5 ~ %95 (Non Condensing) |
|
Light Levels |
Max. 6.000 Lux (fluorescence) |
|
Drop Durability |
Designed to with stand 1.5M
drops |
