● Direct Thermal And Thermal
Printing
● 300 DPI Printing Resolution
● Max. 105,7 mm Printing Width
● Max. 762 mm Printing Length
● Max. 102 mm / Sec Printing Speed
● 8 MB DRAM and 4 MB Flash ROM
● EZPL, GEPL and GZPL Support
● 300 Meter Ribbon Capacity
● PS2 keyboard connection for standalone applications
● Adjustable, auto-adapt sensor
● User panel with backlit LCD display
● LPT, RS232C, USB, Ethernet and PS/2 Port
Operational | |
Printing method | Direct thermal and thermal transfer |
Printing resolution | 300 DPI (12 dots/mm) |
Printing speed (Maximum) | 102 mm/saniye |
Printing length | 4 ~ 1727 mm |
Printing width | 25 mm ~ 105,7 mm |
Memory | 8 MB DRAM, 4 MB Flash ROM (2 MB User Storage) |
Proccessor | 32 bit RISC micro proccessor |
Control Panel | Backlit graphics LCD display: 128 x 64 dots or 4 lines x 16 characters |
Three mono-color status-LEDs: Power on, Ribbon out, Media out | |
Control keys: FEED, PAUSE and CANCEL | |
Communication interface | Serial port: RS-232 (DB-9) |
USB port (default on) | |
Parallel port: Centronics 36-pin | |
PS2 port | |
CF Card socket (max. 1GB CF card) with real time clock | |
Ethernet 10/100Mbps print server (default off; disables USB when in use) | |
Sensor | Reflective (Adjustable) and See-Through (Center-Fixed) |
Print directions | 0, 90, 180, 270 degree |
Agency listing | CE(EMC), FCC Class A, CB, cUL, CCC |
Physical | |
Width | 285 mm |
Height | 171 mm |
Length (Depth) | 226 mm |
Weight | 3,0 kg |
Material | ABS Plastic |
Electrical | |
Power source (Input) | Auto Switching 100V ~ 240VAC, 50~60Hz |
Environmental | |
Operation temperature | 5 °C ~ 40 °C |
Storage temperature | -20 °C ~ 50 °C |
Operation Humidty | %30 ~ %85 (Non Condensing) |
Storage Humidty | %10 ~ %90 (Non Condensing) |
Label | |
Type | Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper and fabric label |
Width | 25,4 mm ~ 118 mm |
Thickness | 0.06 ~ 0.25 mm |
Roll Inside diameter | 25,4, 38,1 or 76,2 mm |
Roll Outside diameter | 127 mm (Maximum) |
Ribbon | |
Type | Wax, Wax/Resin and Resin |
Ink side | Outside |
Width | 30 mm ~ 110 mm |
Length | 300 Meter (Maximum) |
Roll Inside diameter | 25,4 mm |
Roll Outside diameter | 68 mm (Maximum) |
Software | |
Windows drivers | Windows 2000, XP, VISTA, 7, Windows Server 2003 & 2008 |
Linux drivers | Ubuntu 9.04 & 9.10 |
Label Design programs | Qlabel IV (Free) (for EZPL only) |
Supported barcode printing language | EZPL, GEPL ve GZPL |
Supported graphics formats | Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software |
Resident Fonts |
Bitmap
fonts 6, 8, 10, 12, 14, 18, 24,
30, 16X26 and OCR A & B Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable Bitmap fonts 8 times expandable in horizontal and vertical directions Scalable fonts 90°, 180°, 270° rotatable |
Download Fonts |
Bitmap
fonts 90°, 180°, 270° rotatable,
single characters 90°, 180°,
270° rotatable Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions Scalable fonts 90°, 180°, 270° rotatable |
Code Pages |
CODEPAGE
437, 850, 851, 852, 855, 857,
860, 861, 862, 863, 865, 866,
869, 737 WINDOWS 1250, 1251, 1252, 1253, 1254, 1255 Unicode (UTF8, UTF16) |
Supported Barcode Types | |
1D | Code 39, Code 93, Code 128 (subset A, B, C), UCC/EAN-128 K-Mart, UCC/EAN-128, UPC A / E (add on 2 & 5), I 2 of 5, I 2 of 5 with Shipping Bearer Bars, EAN 8 / 13 (add on 2 & 5), Codabar, Post NET, EAN 128, DUN 14, HIBC, MSI (1 Mod 10), Random Weight, Telepen, FIM, China Postal Code, RPS 128 and GS1 Databar |
2D | PDF417, Datamatrix code, MaxiCode, QR code and Micro QR Code |
Accessories | |
Optional Items | Rotary Cutter |
Label Dispencer | |
External label roll holder for 10” (250 mm) O.D. label rolls | |
External label rewinder | |
802.11 b/g wireless print server (Default off; disables USB when in use. Must remove PS2 port and Ethernet) |
