Decoding Capability |
|
|
1D Linear Barcodes |
Autodiscriminates all standard
1D codes including GS1
Databar™ linear codes |
|
2D Codes |
Aztec Code, Aztec Mesas, Data Matrix, MaxiCode, QR Code |
|
OCR Codes |
OCR-A and OCR-B |
|
Postal Codes |
British Post,
Canadian Post, China Post, Japanese Post, KIX Post, Planet Code
and Postnet |
|
Stacked Codes |
Code 49, GS1 DataBar Composites,
GS1 DataBar Expanded, Stacked,
GS1 DataBar Stacked, GS1 DataBar
Stacked Omnidirectional,
MicroPDF417 and PDF417 |
|
Electrical |
|
|
Input Voltage |
4.2 - 14 VDC |
|
Current |
Operating |
700 mA @ 5 VDC (With Aiming) |
|
470 mA @ 5 VDC (Without Aiming) |
|
Standby/Idle |
55
mA @ 5 VDC (Low Power Mode) |
|
100 mA @ 5 VDC (Normal Mode) |
|
Environmental |
|
|
Light Levels |
0 ~
100.000 Lux |
|
Drop Durability |
2 meter |
|
ESD Protection (Air
Discharge) |
25
kV |
|
Humidty |
%5 ~
%95 (Non Condensing) |
|
Operation temperature |
-30°C ~ 50°C |
|
Storage temperature |
-40 °C ~ 60 °C |
|
IP Standard |
IP65 |
|
Interfaces |
|
SupportedInterfaces |
Keyboard Wedge, RS-232
and USB |
|
Physical |
|
|
Dimensions |
190 mm x 75 mm x 115 mm |
|
Weight |
Reader: 283 gr |
|
Color |
Yellow Or Black |
|
Reading
Performance |
|
Imager Sensor |
VGA Plus (752 x 480 Pixel) |
|
Light Source |
Aiming: Green LED 526 nm ± 30 nm |
|
Illumination: Red LED 626 nm ± 30 nm |
|
Print Contrast Ratio (Min.) |
37% |
|
Reading Angle |
Pitch: ±40°; Roll (Tilt): 360°; Skew (Yaw): ±40° |
|
Reading Indicators |
Beeper (Adjustable Tone), Good Read LED |
|
Resolution (Max.) |
0.130
mm (5 mils) |
|
Scanning Distances |
|
|
PS7000 2D High Density |
5 mil: 66 mm ~ 81 mm |
|
6,6 mil PDF: 45 mm ~ 127 mm |
|
8,3 mil: 25 mm ~ 200 mm |
|
10 mil PDF: 30 mm ~ 167 mm |
|
13 mil: 25 mm ~ 20 mm |
|
PS7000 2D Standard |
6,6 mil PDF: 45 mm ~ 127 mm |
|
8,3 mil: 63 mm ~ 167 mm |
|
8,3 mil Datamatrix: 61 mm ~ 167
mm |
|
10 mil PDF: 30 mm ~ 167 mm |
|
13 mil: 28 mm ~ 310 mm |
|
15 mil Datamatrix: 33 mm ~ 233
mm |
|
35 mil MaxiCode: 25 mm ~ 305 mm |
|
Safety and Regulatory |
|
|
Agency Approvals |
The product meets necessary
safety and regulatory approvals
for its intended use. The Quick
Reference Guide for this product
can be referred to for a
complete list of certifications. |
|
Environmental Compliance |
Complies to China end EU RoHS |
