Bixolon XD3-40D
Entry Level Barcode Printer



● Direct Thermal And Thermal Printing
● 203 DPI Printing Resolution
● Max. 104 mm Printing Width
● Max. 1.000 mm Printing Length
● Max. 127 mm / Sec Printing Speed
● 64 MB SDRAM and 128 MB Flash ROM
● SLCS, BPL-Z and BPL-E Emulation
● Support Windows Linux and MAC Operation Systems

 Operational
 Printing method Direct Thermal
 Printing resolution 203 DPI (8 dots/mm)
 Printing speed (Maximum) 127 mm/sec
 Printing length Max. 1.000 mm
 Printing width Max. 104 mm
 Sensor Transmissive (Fixed), Reflective (Adjustable) and Head Open
 Label
 Type Gap, Black Mark, Notch, Continuous, Fan-Fold
 Width 15 mm ~ 118 mm
 Thickness 0.06 ~ 0.2 mm
 Roll Inside diameter 25,4 mm ~ 76,2 mm
 Roll Outside diameter 127 mm (Maximum)
 Ribbon
 Type Not Used
 Performance
 Memory 64 MB DRAM, 128 MB Flash ROM
 Interface

USB

 Physical
 Width 181 mm
 Height 168 mm
 Depth 222 mm
 Weight 1,7 kg
 Electrical
 Power Type External Power Adaptor (EnergyStar Certified)
 Power source (Input) 100V~240VAC, 50~60Hz
 Environmental
 Operation temperature 0°C ~ 40°C
 Storage temperature -20°C ~ 60°C
 Operation Humidty %10 ~ %80 (Non Condensing)
 Storage Humidty %10 ~ %90 (Non Condensing)
 Software
 Emulation SLCS™, BPL-Z™ and BPL-E™
 Divers, Utilities, Software Windows Driver (Europlus/Seagull)
Linux / Mac CUPS Driver
Virtual COM USB/Ethernet Driver
Utility Program
OPOS Driver
Bartender Ultralite
LabelArtist™-II
 SDK Windows SDK
Linux SDK
 Fonts / Graphics / Symbologies
 Fonts 10 SLCS™ Resident Bitmap Fonts
One SLCS™ Resident Scalable Font
16 BPL-Z™ Resident Bitmap Fonts
One BPL-Z™ Resident Scalable Font
5 BPL-E™ Resident Bitmap Fonts
23 Code Page
Unicode supported (UTF-8, UTF-16LE, UTF-16BE)
 Graphics Supporting user-defined fonts, graphics, formats and logos
 Supported Barcode Types
 1D Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI,Plessey, Postnet, GS1 DataBar (RSS-14),Standard 2-of-5, UPC/EAN extensions,UPC-A, UPC-E, IMB
 2D Aztec, Codablock, Code49, Data Matrix,MaxiCode, MicroPDF417, PDF417,QR Code, TLC39
 Accessories
 Optional Items Peeler, External Paper Supply
