● Corded 2D Imager Scanner
● Light weight, ergonomic design
● 640 X 480 Pixel CMOS Sensor
● 1D:(4 mil) Resolution
● 40 ~ 220 mm scanning distance
● Scanning From Display
● USB Interface
Performans | |
Image Sensor | CMOS |
Resolution | 640 X 480 Pixel |
Light Source | Marking: Red LED, Lighting: White LED |
Resolution | 1D= Min: 4 Mil |
Scanning Distances | 40 - 220 mm (0,33 mm pcs 0.9, EAN13) |
Rotational Sensitivity | Rotation: 360° tilt: ±50° deflection: ±50° |
Field of view angle | Horizontal 36° , Vertical 23° |
Print Contrast (Minimum) | Min: %15 |
Indicators (LED) | Beeper and LED |
Scanning Mod | Manual and Continous |
Supported Interfaces | USB, RS232 and USB-VCP |
Physical | |
Height | 102 mm |
Length | 175 mm |
Width | 73 mm |
Weight | 238 gr |
Case Material | ABS + PC |
Color | Black |
Cable | Standart 2 Meter Straight |
Electrical | |
Voltage | DC 5V |
Current | Operation Mode: 230 mA |
Stand by Mode: 150 mA | |
Environmental | |
Operation temperature | -10°C ~ 55°C |
Storage temperature | -20°C ~ 60°C |
Humidty | %5 ~ %95 (Non Condensing) |
Light Levels | 0 ~ 100.000 Lux |
IP Standart | IP54 |
Drop Test | 1,5 Meter |
Certification | CE |
Decoding Capability | |
1D Barcodes | UPC-A, UPC-E, EAN-8, EAN-13, Code39, Codabar, Code128, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 93, UCC/EAN 128, Code 11, MSI, UK/Plessey, ISBN/ISSN, GS1 Databar Expanded, GS1 Databar, GS1 Databar Limited |
2D Barcodes | QRCode, PDF417, Datamatrix |
