● 2D/Imager barcode Scanner
● 1280 x 800 Pixel Imager Sensor
● 0,076 mm (3 mil) resolution
● 60 fps/s scan speed
● 0 ~ 400 mm scanning distance
● USB HID Interface
| Operational | |
| Light source | Illumination: Red LED |
| CPU | 32 Bit ARM |
| Decoding Depth | 0 ~ 400 mm (13 mil EAN13) |
| Scan Speed | 60 FPS/s |
| Minimum Bar Width | 0,076 mm (3 mil) |
| Scan Mode | Continous & Automatic |
| Indicators | LED : Blue and Red LED |
| Sound : Tune and Volume Tunable Sound Horn | |
| System Interfaces | USB HID, RS-232 and USB-VCP |
| Physical | |
| Height | 132,6 mm |
| Depth | 88 mm |
| Width | 149,8 mm |
| Cable | Standard 2 meter straight |
| Material | Abs Plastic |
| Weight | 841 Gram (Cable inclueded) |
| Electrical | |
| Input Voltage | DC 5V |
| Current Values | Working: ≤500 mA |
| Stand by: ≤210 mA | |
| Environmental | |
| Operation temperature | -10°C ~ 50°C |
| Storage temperature | -20°C ~ 60°C |
| Humidty | %5 ~ %95 (Non Condensing) |
| Decode Capabilities | |
| 1D Barcode Types | Codabar, Code39, Code32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code11, Code128, GS1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, ISBN, ISSN, GS1 DataBar, GS1 DataBar Limited, GS1 DataBar Expanded, MSI, Febraban etc. |
| 2D Barcode Types | PDF417, Micro PDF417, QR Code, Micro QR, Data Matrix, Aztec Code |
