Bixolon SPP-R310
Portable Receipt/Pos Printer



● Direct Thermal Printing
● Max. 72 mm Printing Width
● Max. 100 mm / Sec Printing Speed
● 64 MBit DRAM, 32 MBit Flash ROM
● Support BXL / POS Emulation
● Battery operation for eight hours on single charge
● RS232C, USB and Bluetooth connectivity
● Support Windows, Linux, Android and iOS

Operational
 Printing method Direct thermal
 Printing resolution 203 DPI (8 dots/mm)
 Printing speed Max. 100 mm/sec
 Printing width Max. 72 mm
 Memory SDRAM : 64 MBit (8 MB)
Flash ROM: 32 MBit (4 MB)
 Communication USB (V2), RS-232C and Bluetooth
 Physical
 Width 105 mm
 Height 58 mm
 Length (Depth) 126 mm
 Weight 380 gr
 Material ABS Plastic
 Electrical
 Power input type External adaptor
 Power source (Input) 100 ~ 240 V AC, 50 / 60 Hz
 Power source (Output) DC 12V / 3A
 Battery 7.4 V Li-ion, 2,600 mAh, Rechargeable
 Charging time Up to 4.0 hrs
 Environmental
 Operation temperature -15 °C ~ 50 °C
 Storage temperature -30 °C ~ 70 °C
 Humidty %10 ~ %80 (Non Condensing)
 Sealing IP54
 Drop Rate 1.8 m (6 ft.)
 Media Characteristics
 Type Receipt, Label and Linerless (Optional)
 Width Max. 80 mm
 Thickness 0.07 ± 0.005 mm
 Roll Diameter Up to 50 mm
 Software
 Emulation BXL / POS
 Drivers Windows Driver, OPOS Driver, JPOS Driver,Linux CUPS Driver
 SDKs iOS SDK, Android SDK, Windows SDK
Turkish
 Data Sheets
 Users Manual
 İngilizce
 Data Sheets
 Users Manual Device User Manual
Installation Manual
Bluetooth Connection Manual
iOS Easy Setup Manual
Command Manual
Codepage Manual
Windows Driver Manual
Linux Driver Manual
Windows SDK API Reference Guide
Android SDK Reference Guide
Linux SDK Reference Manual
iOS SDK Reference Manual
 Driver Windows XP/Vista/7/8/10,Server 2003/2008/2012 (32/64 Bit) Driver
Web Driver
Linux Driver (32 Bit)
Linux Driver (64 Bit)
Mac Driver
 S.D.K Windows SDK (For PC and Ce.Net Devices)
For Windows Phone Devices
For Linux Devices
Xamarin
