● Direct Thermal And Thermal Printing
● 300 DPI Printing Resolution
● Max. 103,7 mm Printing Width
● Max. 1270 mm Printing Length
● Max. 152 mm / Sec Printing Speed
● 32 MB DRAM and 16 MB Flash ROM
● PPLA, PPLB and PPLZ Support
● RS-232C, USB (A/B) and Ethernet Port
● For heavy duty labeling demands
Operational | |
Printing method | Direct thermal and thermal transfer |
Printing resolution | 300 DPI (12 dots/mm) |
Printing speed (Maximum) | 127 mm/saniye |
Printing length | 13 ~ 1270 mm |
Printing width | 25 mm ~ 104 mm |
Memory | 16 MB DRAM, 8 MB Flash ROM |
Proccessor | 32 bit RISC micro proccessor |
Operation interface | 3 Button (Feed, Pause and Cancel) |
3 LED (Ready, Media and Ribon) | |
Communication interface | Centronics Parallel, Serial Port (RS-232C) , USB 2.0 and PS/2 port |
Display | Back-lit LCD |
Real Time Clock | Standart |
Sensor | Reflective and transmissive media sensor (Movable) |
Head open switch sensor | |
Ribbon end sensor | |
Print directions | 0, 90, 180, 270 degree |
Agency listing | CE, FCC, UL, CUL, CCC, RoHS |
Physical | |
Width | 250 mm |
Height | 263 mm |
Length (Depth) | 418 mm |
Weight | 11 kg |
Material | Metal |
Electrical | |
Power input type | Power Cable |
Power source (Input) | 100 ~ 240V, 5A, 50/60 Hz |
Environmental | |
Operation temperature | 4 °C ~ 38 °C |
Storage temperature | -20 °C ~ 50 °C |
Humidty | %0 ~ %90 (Non Condensing) |
Label | |
Type | Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper |
Width | 25,4 mm ~ 112 mm |
Thickness | 0.0635 ~ 0.254 mm |
Roll Inside diameter | 25,4 mm |
Roll Outside diameter | 203 mm (Maximum) |
Ribbon | |
Type | Wax, Wax/Resin and Resin |
Ink side | Inside / Outside |
Width | 25,4 mm ~ 110 |
Length | 360 Meter (Max.) |
Roll Inside diameter | 25,4 mm |
Roll Outside diameter | 76 mm (Max.) |
Software | |
Windows drivers | Windows 2000/XP/2003/VISTA/Windows 7 |
Label Design programs | Bartender UltraLite (Free) |
Utility programs | Printer Utility and Font Utility |
Supported barcode printing language | PPLA and PPLB |
Supported graphics formats | PPLA: PCX, BMP, IMG and HEX formats |
PPLB: PCX and binary raster | |
Supported Barcode Types | |
1D | PPLA: Code 39 (standard/with checksum digit), Code 93 Interleaved 2of 5 (standard/with checksum digit/with human readable check digit), EAN-8, EAN-13,UPC-A, UPC-E, Postnet, Codabar, Code 128 subset A/B/C, UCC/EAN-128, UCC/EAN-128 K-MART,UCC/EAN-128 , Random Weight, Plessey, HBIC, Telepen, FIM, UPC2, UPC5, GS1 Data Bar |
PPLB: Code 39 (standard/with checksum digit),Code 93 Interleaved 2 of 5 (standard/with checksum digit/with human readable check digit), EAN-8 (standard/2 digit add-on/5 digit add-on), EAN-13 (standard/2 digit add-on/5 digit add-on), UPC-A (standard/2 digit add-on/5digit add-on), UPC-E (standard/2 digit add-on/5 digit add-on), Postnet, Codabar, Code 128 subset A/B/C, Code 128 UCC (Shipping Container Code), Code 128 Auto, German, Postcode, Matrix 2 of 5, UCC/EAN 128, UPC Interleaved 2 of 5, GS1 Databar | |
2D | PPLA/PPLB: MaxiCode, PDF417, Data Matrix (ECC200 only), QR code, Composite codes |
