● Direct Thermal And Thermal Printing
● 203 DPI Printing Resolution
● Max. 104 mm Printing Width
● Max. 2540 mm Printing Length
● Max. 127 mm / Sec Printing Speed
● 8 MB DRAM and 4 MB Flash ROM
● PPLA and PPLB Support
● A variety of paper sensor system for diverse applications
● Ribbon wound ink-side out or ink-side in available
● Four Auto-Calibration Modes
● Printing noise improved
● LPT, RS-232C and USB Port
Operational | |
Printing method | Direct thermal and thermal transfer |
Printing resolution | 203 DPI (8 dots/mm) |
Printing speed (Maximum) | 127 mm/sec |
Printing length | 5 ~ 2540 mm |
Printing width | 25 mm ~ 104 mm |
Memory | 8 MB DRAM and 4 MB Flash ROM |
Proccessor | 32 Bit RISC proccessor |
Operation interface | 1 button (Feed) and 2 LED (Power and Ready) |
Communication interface | LPT, RS-232 and USB Port |
Sensor | Reflective media sensor (Movable) |
Transmissive media sensor (Fixed and Center) | |
Head open switch sensor | |
Ribbon end sensor | |
Print directions | 0, 90, 180, 270 degree |
Agency listing | CE, FCC, cTUVus, CCC, RoHS |
Physical | |
Width | 225 mm |
Height | 186 mm |
Length (Depth) | 273 mm |
Weight | 2,1 kg |
Material | ABS Plastic |
Electrical | |
Power input type | External adaptor |
Power source (Input) | 100V~240V±10%, 1.8A, 50~60Hz |
Power source (Output) | 24VDC, 2.4A, 60 W Max. |
Environmental | |
Operation temperature | 4 °C ~ 38 °C |
Storage temperature | -20 °C ~ 50 °C |
Humidty | %10 ~ %90 (Non Condensing) |
Label | |
Type | Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper |
Width | 25,4 mm ~ 110 mm |
Thickness | 0.0635 ~ 0.254 mm |
Roll Inside diameter | 25,4 mm |
Roll Outside diameter | 127 mm (Maximum) |
Ribbon | |
Type | Wax, Wax/Resin and Resin |
Ink side | Outside |
Width | 25,4 mm ~ 110 |
Length | 300 Meter (Maximum) |
Roll Inside diameter | 25,4 mm |
Roll Outside diameter | 67 mm (Maximum) |
Software | |
Windows drivers | Windows XP / Vista / 7 / 8 / 8.1, Windows Server 2003 / 2008 / 2012 |
Label Design programs | Bartender UltraLite (Free) |
Utility programs | Printer Utility and Font Utility |
Supported barcode printing language | PPLA, PPLB |
Supported graphics formats |
PPLA:
PCX, BMP, IMG and HEX PPLB: PCX, BMP, GDI and Binary Raster |
Supported Barcode Types | |
1D |
PPLA: Code 39
(standard/with checksum digit),
Code 93 Interleaved 2of 5
(standard/with checksum
digit/with human readable check
digit), EAN-8, EAN-13,UPC-A,
UPC-E, Postnet, Codabar, Code
128 subset A/B/C, UCC/EAN-128,
UCC/EAN-128 K-MART, UCC/EAN-128
, Random Weight, Plessey, HBIC,
Telepen, FIM, UPC2, UPC5, GS1
Data Bar |
2D | PPLA/PPLB: MaxiCode, PDF417, Data Matrix (ECC200 Only), QR code, Composite codes |
Accessories | |
Optional Items | Cutter |
RTC Card | |
Stacker | |
