● 1D Laser Barcode Scanner
● Wifi (433 Mhz) Communication
● Max. 300 meter data transmission range
● 0,076 mm (3 mil) Resolution
● 0 ~ 280 mm Scanning Distance
● IP54 high-level industrial protection
● 1.5 mt (5 ft) drop resistance
| Operational | |
| Light source | 650 nm (±10) visible laser diode (VLD) |
| Supported Barcode Types | 1D (Linear) |
| Minimum Bar Width | 0.076 mm (3 mil) |
| Scan Rate | 300 scans/sec |
| Depth of field | 0 mm ~ 280 mm |
| Scan Width | 30 mm ~ 220 mm |
| Print Contrast | %30 (UPC/EAN %100) |
| Indicators (LED) | LED and Beeper |
| Tilt & Elevation & Deflection | 30° & 65° & 55° |
| Communication | |
| Radio Frequency | 433 MHz ISM frequency |
| Communication Distance | Max. 300 meter (At open places) |
| Decode Capabilities | |
| Barcode Types | EAN-8,EAN-13,UPC-A,UPC-E,Code11,Code 32,Code39 Standard,Code39 Full Ascii,Code 93,Code128,EAN128, UPC-A, UPC-E,EAN/UPC +2/+5,Codabar, Industrial 25,Industrial 2of 5,Interleave 25, Interleave 2of5, Matrix 25, Matrix 2 of 5,MSI/Plessey, UK/Plessey,ISBN,ISSN,GS1-rss14,GS1-Limited,GS1-Expended,GS1 STACKChina post 25 etc. |
| Electrical | |
| Battery Capacity | 2200 mAh |
| Input Voltage | DC 5V |
| Operating Current | Stand By Mod : 110 mA |
| Operation Mod: 35 mA | |
| Working Time | Max. 100.000 Scanning |
| Laser Class | Meet the Grade I National Criteria for Laser Safety |
| EMC | CE, FCC DOC Compliance |
| Physical | |
| Length | 170 mm |
| Width | 71 mm |
| Height | 98 mm |
| Weight | 180 gram |
| Material | Abs Plastic |
| Environmental | |
| IP Standard | IP54 |
| Drop Durability | 1,5 meter |
| Nem | %5 ~ %95 (Non-Condensing) |
