Operational |
|
Light source |
Illumination: 650 nm Red LED |
|
CPU |
32 Bit ARM |
|
Decoding Depth |
5 ~ 150 mm @(13 mil Code 39) |
|
Scan Speed |
120 FPS/s |
|
Mobile Tolerence |
1.5m/s |
|
Minimum Bar Width |
0,01 mm (4 mil) |
|
Scan Mode |
Continous & Automatic |
|
Scanning Direction |
Omnidirectional |
|
Scanning Angle |
Deflection 360° Inclination ±65° Rotation ±60° |
|
Indicators |
LED : Blue and Red LED |
|
Sound : Tune and Volume Tunable Sound Horn |
|
System Interfaces |
USB HID, RS-232 and USB-VCP |
|
Physical |
|
Height |
153 mm |
|
Depth |
53 mm |
|
Width |
88 mm |
|
Cable |
Standard 2 meter straight |
|
Material |
Abs Plastic |
|
Weight |
296.2 Gram (Cable inclueded) |
|
Electrical |
|
Input Voltage |
DC 5V |
|
Current Values |
Working: <175 mA |
|
Stand by: <145 mA |
|
Environmental |
|
Operation temperature |
-10°C ~ 50°C |
|
Storage temperature |
-20°C ~ 60°C |
|
Humidty |
%5 ~ %95 (Non Condensing) |
|
Light Levels |
0~5000Lux (fluorescence), 0~100,000 Lux (sunlight) |
|
Decode
Capabilities |
|
|
1D Barcode Types |
Codabar, Code39, Code32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code93, Code128, GS1-128, UPC-A, UPC-E, EAN 8, EAN 13, GS1 DataBar(RSS14), GS1 DataBar Limited, GS1 DataBar Expanded etc. |
|
2D Barcode Types |
PDF417, Micro PDF417, QR Code, Micro QR, Data Matrix, Aztec Code, Maxicode, Hanxin code |
