Operational |
|
Printing method |
Thermal Line |
|
Printing resolution |
8 dots/mm, 576 dots/line |
|
Printing speed |
Max. 200 mm/sec |
|
Printing width |
Max. 72 mm |
|
Communication
interface |
USB and Ethernet |
|
Drawer Port |
1 Port |
|
Flash Memory |
8 Mbit |
|
Data receiving
buffer |
128 KByte |
|
Sensors |
Paper Near End Sensor |
|
Paper End Sensor |
|
Auto Cutter |
Type: Guillotine |
|
Life 1.00,000 Cuts |
|
MCBF |
60 million lines |
|
TPH Life |
100 km |
|
Physical |
|
Width |
167 mm |
|
Height |
140 mm |
|
Length (Depth) |
124 mm |
|
Weight |
1.3 Kg |
|
Material |
ABS Plastic |
|
Color |
Dark Grey |
|
Electrical |
|
Power input type |
External adaptor |
|
Power source |
AC100 ~240V (±10%) DC 24V, 1.5A |
|
Environmental |
|
Temperature |
Operation : 0°C ~ 45°C |
|
Storage: -10°C ~ 60°C |
|
Humidty |
Operation : %10 ~ %80 (Non Condensing) |
|
Storage: %20 ~ %90 (Non Condensing) |
|
Paper |
|
Type |
Thermal receipt paper |
|
Width |
Max. 79,5 mm (±0,5 mm) |
|
Roll Inside Diameter |
13 mm (Min.) |
|
Roll Outside diameter |
80 mm (Max.) |
|
Thickness |
0.06 mm ~ 0.07 mm |
|
Software |
|
Windows
Compatibility |
Win Xp, Win 7, Win 8, Win 10, Win 11, Linux CUPS, MacOS ve OPOS |
|
Emulation |
ESC/POS |
|
Supported barcodes types |
UPC-A,UPC-E,EAN-13,EAN-8,Code39,ITF,Codabar,Code 93,Code 128,Code 11, MSI, QrCode ve PDF417 |
|
SDK |
Windows, Android ve iOS |
|
Fonts |
|
Character Set |
ANK, GB18030(Chinese) |
|
Print Size |
ANK: 12 x24,9x17, Chinese: 24 x 24 |
|
Character Per Line |
FontA:48 FontB:64 |
