Performance |
|
Imager Sensor |
BS8060-3V: 2500 Pixel Linear Imager |
|
BS8060-2T: 752 x 480 Pixel CMOS |
|
Decode Capabilities |
BS8060-3V: 1D |
|
BS8060-2T: 1D and 2D |
|
Minimum Bar Width |
0.127 mm (5 Mil) |
|
Scanning Angle |
BS8060-3V: Pitch: ±55°; Roll: ±25°; Skew: ±75° |
|
BS8060-2T: Pitch: ±50°; Roll: ±360°; Skew: ±60° |
|
Indicators (LED) |
LED and Beep volume |
|
Print Contrast |
≥%30 |
|
Memory |
1 MB |
|
Interfaces |
Micro USB, Bluetooth HID/SPP/BLE Profiles |
|
Communication |
|
Radio Technology |
2.4 - 2.5GHz ISM band, compatible with Bluetooth 4.0/3.0/2.1+EDR |
|
Communication Distance |
Max. 50 metre (Open Space) |
|
Physical |
|
Dimensions |
Height: 24,5 mm |
|
Length: 88 mm |
|
Width: 46 mm |
|
Weight |
62 Gram |
|
Electrical |
|
Power Adaptor (Optional) |
Input: AC100~240V, 50~60Hz |
|
Output: 5VDC,500mA |
|
Current |
BS8060-3V |
Operation : 75mA (Bluetooth is on) |
|
Standby : 5mA |
|
BS8060-2T |
Operation : 260mA (Bluetooth is on) |
|
Standby : 10mA |
|
Battery Type |
3.7V 900 mAh rechargeable Li-ion battery |
|
Charging Time |
3~5 hours |
|
Battery Life |
BS8060-3V: 11 Hours ((Synchronous mode, scan and send data once per 6s) |
|
BS8060-2T: 6 Hours ((Synchronous mode, scan and send data once per 6s) |
|
Environmental |
|
Operation temperature |
-20°C ~ 50°C |
|
Storage temperature |
-40°C ~ 70°C |
|
Humidty |
%5 ~ %95 (Non Condensing) |
|
ESD |
±8 KV (Contact discharge), ±15 KV (Air discharge) |
|
Drop |
1,2 m drop to concrete |
|
IP Standard |
IP42 |
|
Certifications |
|
Certifications |
FCC Part15 Class B, CE EMC Class B |
|
Decode
Capabilities |
|
1D Barcodes |
Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, ISSN, Interleaved 2 of 5, ISBN, Code 93, UCC/EAN-128, GS1 Databar, etc |
|
2D Barcodes |
PDF417, QR Code, Data Matrix, etc |
|
Scanning Distances |
|
BS8060-3V |
Code 39 : (5 mil) 105 mm ~ 175 mm |
|
Code 128 : (10 mil) 60 mm ~ 340 mm |
|
EAN-13 : (13 mil) 55 mm ~ 410 mm |
|
BS8060-2T |
EAN-13 : (13 mil) 60 mm ~ 380 mm |
|
Code 39 : (5 mil) 60 mm ~ 380 mm |
|
Datamatrix : (10 mil) 85 mm ~ 140 mm |
|
QrCode : (15 mil) 40 mm ~ 190 mm |
|
PDF417 : (6,7 mil) 85 mm ~ 150 mm |
