Print Parameter |
|
Printing method |
Thermal Line |
|
Printing resolution |
203 DPI / 180 DPI |
|
Printing speed |
Max. 200 mm/sec |
|
Printing width |
Max. 72 mm |
|
Paper |
|
Type |
Continuous thermal receipt / Recycled thermal paper |
|
Width |
Max. 80 mm |
|
Paper Exit |
Front Exit |
|
Barcode |
|
1D |
UPC-A, UPC-E, EAN-8, EAN-13, CODE39, ITF, CODABAR, CODE128, CODE93 |
|
2D |
QRCode, PDF417 |
|
Fonts |
|
Chinese |
Simplified /Traditional (24×24) |
|
Alphanumeric |
Font A 12×24,Font B 9×17 |
|
Character Set |
Chinese, International Character Sets, Korean, Japanese |
|
Interface |
|
Standard |
1*USB Type-B，Ethernet，Cash drawer |
|
Optional |
Wi-Fi，Bluetooth |
|
Sensor |
|
Standard |
Over-temperature detection, paper out detection, cover up detection, cutter jam detection |
|
Memory |
|
RAM |
4 MB |
|
Flash |
4 MB |
|
Power Supply |
|
Input |
AC 100~240 V，50/60 Hz |
|
Output |
DC 24 V 1.5 A |
|
Software |
|
Driver |
Windows 7/8/10，Windows Server 2008/2012/2016, Linux，Javapos，OPOS，MacOS |
|
Utility |
Windows 7/8/10，Windows Server 2008/2012/2016 |
|
Reliability |
|
TPH |
100 km |
|
Cutter life |
1 million |
|
Environment |
|
Operating temperature |
0°C ~ 45°C / 25%~85%RH |
|
Storage temperature |
-20°C ~ 60°C / 5%~95%RH |
|
Printer Dimension |
|
L × W × H |
145 mm × 123.5 mm × 120.3 mm |
|
Certification |
|
Certification |
CCC，CE，FCC |
