● 1D/2D Imager barcode
Scanner
● 1280 x 800 Pixel Image Capture
●
Aggressive scanning
performance
●
Advanced
Data Formatting
●
Read barcodes from mobile
phone and PC screen
●
Support Digimarc Barcode
● Schockproof to 1,2 meters
| Decoding Capability | |
| 1D Linear Barcodes | Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes. |
| 2D Barcodes | Aztec code, Data Matrix, MaxiCode, QR Code |
| Postal Codes | Australian Post, British Post, Canadian Post, China Post, IMB, Japanese Post, KIX Post, Planet Code, Portuguese Post, Postnet, Royal Mail Code (RM4SCC), Swedish Post |
| Stacked Codes | GS1 DataBar Composites, GS1 DataBar Composites, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, Micro PDF417, PDF417 |
| Digital Watermarks | Optional support for Digimarc® Barcodes/GS1 DW Code |
| Electrical | |
| Current | Operating (Typical): < 500 mA |
| Standby/Idle (Typical): < 300 mA | |
| Input Voltage | 5 VDC (±10%) |
| Environmental | |
| Ambient Light | 0-86.100 Lux |
| Drop Resistance | Withstands repeated drops from 1.2 mt / 4.0 ft onto a concrete surface |
| ESD Protection (Air Discharge) | 25 kV |
| Operation temperature | 0°C ~ 40°C |
| Storage temperature | -40 °C ~ 70 °C |
| Humidty | %5 ~ %95 (Non Condensing) |
| Particulate and Water Sealing | IP52 |
| Interfaces | |
| Interfaces | USB Keyboard, USB COM, OEM (IBM) USB, RS-232 |
| Physical | |
| Tilting Riser | 6.0 x 7.5 x 15.0 cm |
| Stand | 6.0 x 7.5 x 10.6 cm |
| Weight | Tilting Riser: 240.0 g |
| Optional Features | |
| EAS Features |
checkpoint Systems:
Integrated eAS hardware will work with counterpoint IV, V, VI
and VII models Sensormatic: Good Read Acknowledgement |
| Value Addes Features | Diagnostic Reporting; Productivity Index Reporting™ (PIR) |
| Reading Performance | |
| Aiming | LED aimer for precision scanning |
| Image Capture | 1 MP, 1280 x 800 pixels |
| Graphic Formats | JPEG, BMP |
| Print Contrast Ratio (Max) | %25 |
| Reading Angle | Pitch: +/- 65°; Roll (Tilt): 0 - 360°; Skew (Yaw): +/- 75° |
| Reading Indicators |
Beeper (Adjustable Tone and Volume) Datalogic ‘Green Spot’ Good Read Feedback Good Read LED |
| Resolution (Max.) | 0,130 mm (5 Mil) |
| Scanning Distances | |
| 1D / Linear Codes |
5 mils: 2,5 cm ~ 9.0 cm 7.5 mils: 0 ~ 17 cm 10 mils: 0 ~ 21 cm 13 mils: 0 ~ 25 cm (UPC) 20 mils: 1 ~ 3 cm |
| Optional Codes |
6,5 mils PDF: 2,5 cm ~ 11 cm 13 mils Datamatrix: 0 ~ 17 cm 16 mils PDF: 0 ~ 2 cm 24 mils Datamatrix: 0 ~ 25 cm |
| Safety and Regulatory | |
| Agency Approvals | The product meets necessary safety and regulatory approvals for its intended use. |
| Environmental Compliance | Complies to China RoHS, Complies to EU RoHS |
| LED Classification | EN62471 and IEC62471 Lamp Illumination |
| Tools | |
| Magellan OSP | Magellan On-Screen Programming (OSP) configuration software is available for download at no charge. |
| OPS/JAVAPOS | JavaPOS Utilities are available for download at no charge. OPOS Utilities are available for download at no charge. |
| Remote Host Download | Lowers service costs and improves operations. |
