● 1D/2D Imager barcode Scanner
● CCD Solid-State Imager Sensor
● 325 Scan per second
● 0,076 mm (3 mil) resolution
● 20 ~ 800 mm scanning distance
● "Green Spot" Light For Good Read Feedback
● IP52 Standard
● Schockproof to 1,8 meters
| Reading Performance | |
| Image Sensor | CCD Solid-State |
| Light source | 630 - 670 nm Dual LED |
| Print Contrast (Minimum) | 15% |
| Scan Rate | 325 Scan/Sec |
| Scan Angle | Pitch: +/- 65°; Roll (Tilt): +/- 35°; Skew (Yaw): +/- 65° |
| Indicators (LED) | Adjustable Beeper Tone , Datalogic ‘Green Spot’ Good Read Feedback; Good Read LED; Good Transmission |
| Resolution | 0.076 mm (3 mil) |
| Physical | |
| Height | 181 mm |
| Depth | 100 mm |
| Width | 71 mm |
| Weight | 169 gr (Without Stand) |
| Color | Black or White |
| Interfaces | |
| Support Interface | USB, RS-232C, IBM4644, Keyboard Wedge and Wand |
| Electrical | |
| Input Voltage | 4,75 - 5,25 VDC |
| Currnet | Operation: 245 mA @5VDC |
| Standby :120 mA @5VDC | |
| Environmental | |
| Light Levels | 100.000 Lux |
| Operation temperature | 0°C ~ 55°C |
| Storage temperature | -20 °C ~ 70 °C |
| Humidty | %0 ~ %90 (Non Condensing) |
| Drop Durability | 1,8 meter |
| IP Standard | IP52 |
| ESD Protection (Air Discharge) | 16 kV |
| Decoding Capability | |
| 1D Linear barcodes | Autodiscriminates all standard 1D codes including GS1 Databar™ linear codes |
| Postal Codes | China Post |
| Stacked Codes | GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional |
| Scanning Distances | |
| Scanning Distances | 5 mil: 60 mm ~ 180 mm |
| 7,5 mil: 35 mm ~ 300 mm | |
| 10 mil: 20 mm ~ 450 mm | |
| 13 mil: 30 mm ~ 600 mm | |
| 20 mil: 30 mm ~ 800 mm | |
| Safety and Regulatory | |
| Agency Approvals | The product meets necessary safety and regulatory approvals for its intended use. The Quick Reference Guide for this product can be referred to for a complete list of certifications. |
| Environmental Compliance | Complies to China end EU RoHS |
| Optional Features | |
| EAS | Checkpoint® Systems: GD4110-WH EAS |
