● Direct Thermal Printing
● Max. 72 mm Printing Width
● Max. 100 mm / Sec Printing Speed
● 64 MBit DRAM, 32 MBit Flash ROM
● Support BXL / POS Emulation
● Battery operation for eight hours on single charge
● RS232C, USB and Bluetooth connectivity
● Support Windows, Linux, Android and iOS
| Operational | |
| Printing method | Direct thermal |
| Printing resolution | 203 DPI (8 dots/mm) |
| Printing speed | Max. 100 mm/sec |
| Printing width | Max. 72 mm |
| Memory | SDRAM : 64 MBit (8 MB) |
| Flash ROM: 32 MBit (4 MB) | |
| Communication | USB (V2), RS-232C and Bluetooth |
| Physical | |
| Width | 105 mm |
| Height | 58 mm |
| Length (Depth) | 126 mm |
| Weight | 380 gr |
| Material | ABS Plastic |
| Electrical | |
| Power input type | External adaptor |
| Power source (Input) | 100 ~ 240 V AC, 50 / 60 Hz |
| Power source (Output) | DC 12V / 3A |
| Battery | 7.4 V Li-ion, 2,600 mAh, Rechargeable |
| Charging time | Up to 4.0 hrs |
| Environmental | |
| Operation temperature | -15 °C ~ 50 °C |
| Storage temperature | -30 °C ~ 70 °C |
| Humidty | %10 ~ %80 (Non Condensing) |
| Sealing | IP54 |
| Drop Rate | 1.8 m (6 ft.) |
| Media Characteristics | |
| Type | Receipt, Label and Linerless (Optional) |
| Width | Max. 80 mm |
| Thickness | 0.07 ± 0.005 mm |
| Roll Diameter | Up to 50 mm |
| Software | |
| Emulation | BXL / POS |
| Drivers | Windows Driver, OPOS Driver, JPOS Driver,Linux CUPS Driver |
| SDKs | iOS SDK, Android SDK, Windows SDK |
| Turkish | ||
| Data Sheets |
 |
|
| Users Manual |
|
|
| İngilizce | ||
| Data Sheets |
|
|
| Users Manual | Device User Manual |
|
| Installation Manual |
|
|
| Bluetooth Connection Manual |
|
|
| iOS Easy Setup Manual |
|
|
| Command Manual |
|
|
| Codepage Manual |
|
|
| Windows Driver Manual |
|
|
| Linux Driver Manual |
|
|
| Windows SDK API Reference Guide |
|
|
| Android SDK Reference Guide |
|
|
| Linux SDK Reference Manual |
|
|
| iOS SDK Reference Manual |
|
|
| Driver | Windows XP/Vista/7/8/10,Server 2003/2008/2012 (32/64 Bit) Driver |
|
| Web Driver |
|
|
| Linux Driver (32 Bit) |
|
|
| Linux Driver (64 Bit) |
|
|
| Mac Driver |
|
|
| S.D.K | Windows SDK (For PC and Ce.Net Devices) |
|
| For Windows Phone Devices |
|
|
| For Linux Devices |
|
|
| Xamarin |
|
|
