Newland NQuire500
(Skate II)
Information Terminal
(Price Checker)



● Android 13 (Tiramisu) Operation System
● Octa Core 2.0 Ghz CPU
● 4 GB RAM and 64 GB ROM
● 5 Inch Color Touch Screen
● USB, Wifi, Bluetooth, 4G And Ethernet Interface
● 2D Imager Barcode Scanner

 Model  Operation System RAM ROM Wifi Bluetooth 4G
 NLS-NQUIRE500-W4-SL  Android 13 4 GB 64 GB Yes Yes Yes
System
 CPU Octa Core 2.0 Ghz
 Memory 4 GB RAM, 64 GB Flash ROM
 Operation System Android 13 (Tiramisu)
 Sensors Gravity Sensor, Infrared Sensor
 Keypad Up/down keys, Vol+/Vol-keys, Menu key
 Camera Front camera: 8 MP (MegaPixel)
 Notifications Speaker and multicolour LEDs
 Expansion Slot SD Card (Max. 128 GB)
Display
 Type Full Touch and Capacitive
 Size 5" (Inch)
 Resolution 854 x 480 Pixel
Data Capture
 Supported Barcode Types 1D and 2D
 Barcode Types 1D All major 1D symbologies
2D All major 2D symbologies
 Scan Distance 1D EAN-13 (13 Mil): 70 mm ~ 610 mm
Code 39 (5 Mil): 110 mm ~ 290 mm
2D PDF417 (6.67 Mil): 110 mm ~ 230 mm
DATAMATRIX (10 Mil): 110 mm ~ 260 mm
QRCODE (15 Mil): 55 mm ~ 410 mm
Connectivity
 USB USB Type-C (1 Pcs)
 Wifi Wifi 802.11 a/b/g/n/ac (2.4 Ghz and 5 Ghz)
 Bluetooth Bluetooth 5.2
 Ethernet RJ45, 802.3 af/at POE(Power Over Ethernet)
 WWAN 2G 850/900/1800/1900 Mhz
3G WCDMA (B1, B2, B5, B8); CDMA:1X EVDO (BC0); TD-SCDMA: B34/39
4G TDD-LTE (B34,B38, B39, B40, B41), FDD-LTE (B1,B2,B3,B5, B7, B8, B20, B28 a&b)
SIM: Nano+Nano/Nano+TF
 RFID /NFC (Optional) Frequency 13.56 Mhz
Tags ISO14443A/B, MIFARE, FeliCa, NFC Forum Tags, ISO15693
 GPS GPS (AGPS), GLONASS, Beidou, Galileo
Physical
 Dimensions Width 156,5 mm
Height 100,4 mm
Depth 29 mm
 Material ABS Plastic
Power
 Power Source Input AC100 ~ 240V, 50 ~ 60Hz
Output 12V,3A
Environmental
 Operating Temperature -10°C ~ 50°C
 Storage Temperature -20°C ~ 60°C
 Humidity %5 ~ 90 (Non Condensing)
 IP Standard IP54 (Front Only)
Software
 MDM Ndevor
Turkish
 Data Sheets
 English
 Data Sheets
 Manual  User Manual
Progamming Manual
