● Android 4.4 (Kit Kat) Operation Systems
● MT6582 Dual Core 1,3 Ghz proccessor
● 1 GB DDR-RAM, 8 GB eMMC ROM
● 4,5 Inch (960 x 540 pixel) TFT, IPS LCD Display
● Wifi, Bluetooth, RFID, GPRS (3,5G), GSM, GPS technology
● 1,2 mt (4 ft) drop resistance
● IP65 Protection Class
● 13MP CMOS Sensor Autofocus Camera with Flash
| System | |
| Micro Processor | MT6582 Dual Core 1,3 Ghz Micro Processor |
| Memory | 1 GB Mobile DDR RAM, 8 GB eMMC Flash ROM |
| Operation System | Android 4.4 (Kit Kat) |
| Expansion Slot | MicroSD Card (Max. 32 GB) |
| Display | |
| Display Type | QHD Capasitive LCD |
| Dimension | 4,5" (Inch) |
| Resolutioin | 960 x 540 Pixel |
| Touch Panel | 5-point capacitive |
| Keypad | |
| Keypad | ESC and Enter |
| Indicator | |
| Types | LED and Vibrator |
| Barcode Scanner | |
| Type | 2D Imager Barcode Scanner |
| Supported Barcode Types | 1D: Code 128, EAN-8, EAN-13, UPC-A,UPC-E, Code 39, Code 93, EAN128,Codabar, Interleaved 2 of 5, Matrix 2 of 5,ISBN/ISSN, UCC/EAN-128,GS1 Databar |
| 2D: PDF417,QC Code (Model 1/2, mirco), DataMatrix (ECC200,ECC000,050,080,100,140) | |
| Audio | |
| Types | 3.5mm Audio Jack |
| Reciever | |
| Microphone | |
| Input Devices | |
| Types | Keypad |
| Touch Screen | |
| Full Alphanumeric Software Keyboard | |
| Barcode Scanner | |
| Camera | 13 Megapixel (With Flash) |
| Regulatory Approvals | |
| Regulatory Approvals | CE EN55022/24 & FCC Part 158, RF (CE, FCC) |
| Communication | |
| USB | USB 2.0 OTG / USB Host 1.1 |
| WLAN | 802.11 b/g/n |
| PAN | Bluetooth 2.0 |
| GPS | Support A-GPS |
| RFID Reader | |
| Frequency | 13.56 Mhz |
| Tag Support | ISO15693, ISO14443A , ISO14443B (NFC Supported) |
| Power | |
| Input Voltage | AC 100-240V, 50-60 HZ |
| Output Voltage | 5VDC, 2A |
| Main Battery | 3,7V 4200 mAH Li-Ion Battery |
| Working time | Stand By: 6 Days |
| Operation: 15 Hours (Wifi Off) | |
| Operation: 8 Hours (Wifi On) | |
| Charging time | Max: 6 Hours (With External Adapter) |
| Charging Voltage | DC 5V |
| Physical | |
| Case Material | ABS + PC |
| Weight | 280 gram (Battery Included) |
| Dimensions | Length: 147 mm, Thickness: 21 mm, Width:74 mm |
| Enviromental | |
| Operating temperature | -10°C ~ 50°C |
| Storage temperature | -20°C ~ 65°C |
| Relative Humidity | %20 ~ %90 (Non-Condensing) |
| Drop test to Concrete | 1,2 meter |
| Environmental Sealing | IP65 |
