Operational |
|
Printing method |
Thermal Line |
|
Printing resolution |
8 dots/mm, 576 dots/line |
|
Printing speed |
Max. 300 mm/sec |
|
Printing width |
Max. 72 mm |
|
Communication
interface |
RS-232C, USB and Ethernet |
|
Drawer Port |
1 Port |
|
Flash Memory |
8 Mbit |
|
Data receiving
buffer |
128 KByte |
|
Auto Cutter |
Type: Partial |
|
Life 1.500,000 Cuts |
|
TPH Life |
150 km |
|
Physical |
|
Width |
140 mm |
|
Height |
127 mm |
|
Length (Depth) |
180 mm |
|
Weight |
1 Kg |
|
Material |
ABS Plastic |
|
Color |
Black |
|
Electrical |
|
Power input type |
External Electrical Adapter |
|
Power source |
Input: AC110V ~ 220V, 50 ~ 60 Hz |
|
Output: DC 24V, 2A |
|
Cash Drawer Output |
DC 24V, 1A |
|
Environmental |
|
Temperature |
Operation : 0°C ~ 45°C |
|
Storage: -10°C ~ 60°C |
|
Humidty |
Operation : %10 ~ %80 (Non Condensing) |
|
Storage: %10 ~ %90 (Non Condensing) |
|
Paper |
|
Type |
Thermal receipt paper |
|
Width |
Max. 79,5 mm (±0,5 mm) |
|
Roll Inside Diameter |
13 mm (Min.) |
|
Roll Outside diameter |
80 mm (Max.) |
|
Thickness |
0.06 mm ~ 0.08 mm |
|
Software |
|
Windows
Compatibility |
Windows XP/Vista/7/8/8.1/10, Linux |
|
Supported printing language |
Compatible with command ESC/POS |
|
Supported barcodes types |
1D |
UPC-A, UPC-E, JAN/EAN-13, JAN/EAN-8, CODE39, ITF, CODABAR, CODE93, CODE128 |
|
2D |
QrCode, Pdf417 |
|
Fonts |
|
Character Size |
ANK Font A：1.5x3.0 mm (12×24 Dots) |
|
ANK Font B：1.1x2.1 mm (9×17 Dots) |
|
Chinese：3.0×3.0 mm (24×24 Dots) |
|
Line Space |
3.75 mm (Changeable by Commands) |
