Newland NQuire800
Industrial Windows Tablet



● Windows 10 Pro Operation Systems
● 1.44 ~ 1.92 Ghz Proccessor
● 2/4 GB RAM, 32/64 GB ROM
● 8 Inch Touch Screen
● USB, Wifi, Bluetooth, GPRS (4G), GSM, GPS technology
● 1,2 mt (4 ft) drop resistance
● IP67 Protection Class
● 2D Imager Barcode Scanner

 Model Operation System  RAM  ROM
 NQuire800 II Windows 10 Pro (32 Bit)  2 GB  32 GB
 NQuire800 II Plus Windows 10 Pro (32 Bit)  4 GB  64 GB
 Performance
 Chip Intel Atom® x5-Z8350
 CPU 1.44 GHz ~ 1.92 GHz, 64-Bit Quad Core
 Memory NQuire800 II: 2 GB RAM, 32 GB ROM
NQuire800 II Plus: 4 GB RAM, 64 GB ROM
 Operation System NQuire800 II: 32 Bit Windows 10 Pro
NQuire800 II Plus: 64 Bit Windows 10 Pro
 Sensors G-Sensor (Gravity Acceleration Sensor)
 External Memory Slot up to 128GB (supports SDHC/SDXC cards)
 Display
 Size 8" (Inch)
 Resolution 800 x 1280 Pixel
 Luminance 380 cd/m2
 Contrast Ratio Min: 600:1, Typical: 800:1
 Communication
  Micro USB
Micro SD
Pogo PIN Connector
GPS / GLONASS
Bluetooth 4.0
 Network
 Wifi 802.11 ac/a/b/g/ (2.4 Ghz and 5 Ghz)
WEP, WPA2-Personal AES, WPA2-Enterprise AES, 8-2.11x WEP with EAP method PEAP, EAP-SIM, EAP-TTLS
 3G Micro SIM (3FF)
Band: 900 / 2100 MHz
 Multimedia
 Rear Camera 5 MP(Auto Focus)
 Video HD (1280 x 720) @ 30FPS
 Battery
 Type 8,000 mAh Lithium-polymer
 Battery Life Use: 5 ~ 7 Hours (Depending on the Number of Programs Used)
StandBy: 250 Hours
 Physical
 Dimensions Width 147 mm
Height 235 mm
Thickness 22 mm
 Weight 875 Gram
 Data Capture
 1D Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93, UCC / EAN-128, GS1 Databar, Matrix 2 of 5, Code 11, Industrial 2 of 5, Standard 2 of 5, Plessey, MSI-Plessey
 2D PDF417, Data Matrix ECC200 / 000 / 050 / 080 / 100 / 140, QR-Code
 Certifications
 Industrial Protection IP67 (30 Minute, Resistance to water and dust up to 1 meter)
 Durability drop tested up to 1.2M
Tested to IEC 60068232 standards up to 1.2M; 6 Faces, 4 Corners, 2 Cycles onto cement or steel floor
 Laser Safety Complies to IEC2 / FDA II,IEC60825 / EN60825-1 Standarts
 Device Features
  Built-in Stylus
2 x Capacitive shortcut keys (front bezel)
